Water Pump Controller

Water Pump Controller

The 3-phase & single phase variant makes you control every water tube at home and at farms or agriculture lands. A smart key chain provided with it to operate the motor effectively for efficient use. The contactor box in the panel eases the installation process and also protects your motor from a dry run, phase reversal, overload, and phase failure. IOTO Water Pump Controller is constantly monitoring the health status of your motor panel. You can view the up-to-date realtime heath status of your motor in the IOTO app.

Features:

• Schedule on/off timings as per your convenience
• Operate motor from anywhere in the world
• The IOTO App enables you to control the motor in your native language
• Every agricultural motor can be connected
• It’s an easy-go for farmers as smart key chain consists on/off buttons

General Data :

• Storage/operating temperature: upto 60 degree Celsius.
• Mounting type: Pole and Surface
• Mounting orientation: Vertical 3 phase 3 wire connection
• I/p: 360-440 VAC50/60Hz, Max: 4A
• O/p: up to 15 HP (available in 7.5 Hp & 15 Hp variations.Maximum Resistive
• Electronic board Power Consumption Max. 9W
• Connectivity: NB-IoT
• Metal box: Weather proof ABS plastic
• Contactor: SG

Electrical Data :

• Over load protection: (As per motor rating) Variable with 0 to 60 sec time
• Under load protection: (As per motor rating) Variable with 0 to 60 sec time
• Over voltage protection: (300-500 volt) Variable with 0 to 60 sec time
• Under voltage protection: (300-500 volt) Variable with 0 to 60 sec time
• Single phase preventer: with current and voltage sensing
• Switch: Auto-manual
• Power and control wiring: Copper
• Output: Terminals
• Indicating lamp: R-Y-B (20 Sq.mm LED Type)
• Push Button: On/Off (20 Sq.mm)
