Aerator

Aerator

IOTO’s Smart aerator motor panel lets you smartly control your aerator motors more efficiently. Control them from anywhere, measure real-time power consumption, schedule your pumps according to your convenience. Get all this with full protection for your motors.

 IOTO  Mobile App is constantly monitoring the health status of your Aerator. You can view the up-to-date realtime heath status of your Aerator in the IOTO app.

Features:

• Schedule on/off timings as per your convenience
• Operate Aerator from anywhere in the world
• The IOTO App enables you to control the motor in your native language
• It’s an easy-go for users as smart key chain consists on/off buttons

General Data :

• Storage/operating temperature- up to 90 degree Celsius.
• Mounting type: Pole and surface
• Mounting orientation: vertical 3 phase 3 wire connection
• I/p: 340-450 VAC
• O/p: up to 10 HP & Special variant 100HP.
• Number of controls 4 - 4 Aerators can be controlled independently
• Electronic board Power Consumption Max. 9W
• GSM/GPRS connectivity (2G): NbIoT Support in future
• Metal box: weather proof ABS plastic
• Contactor: SG
• Power measurement with +/- 0.5% accuracy

Electrical Data :

• Over load protection: (As per motor rating) Variable with 0 to 60 sec time
• Under load protection: (As per motor rating) Variable with 0 to 60 sec time
• Over voltage protection: (300-500 volt) Variable with 0 to 60 sec time
• Under voltage protection: (300-500 volt) Variable with 0 to 60 sec time
• Single phase preventer: with current and voltage sensing
• Switch: Auto-manual
• Power and control wiring: Copper
• Output: Terminals
• Indicating lamp: R-Y-B (20 Sq.mm LED Type)
• Push Button: On/Off (20 Sq.mm)
